30cum/H, 40cum/H, 60cum/H Mobile Concrete Mixing Plant From Good Manufacturer
Mobile Portable Concrete Batching Plant with Capacity of 25/35/50/60/75/100/120cmb Per HourInstall Video of Mobile Portable Concrete Mixing Plant / Batching Plant:micfocus.en.made-in-china.comWhy would our clients choose FOCUS mobile Concrete Mixing Plant / Batching Plant?FOCUS MACHINERY boasts an a......
Send Inquiry
Product Description
Mobile Portable Concrete Batching Plant with Capacity of 25/35/50/60/75/100/120cmb Per Hour
Install Video of Mobile Portable Concrete Mixing Plant / Batching Plant:
micfocus.en.made-in-china.com
Why would our clients choose FOCUS mobile Concrete Mixing Plant / Batching Plant?
FOCUS MACHINERY boasts an award-wining mobile concrete mixing plant product range with capacity from 25cbm to 120cbm hourly.
This series of mobile concrete mixing plant adopts semi-pulling structure with running system and equipped with standard coupling pin, hence can be dragged by a tractor at the maximum speed of 40km/h.
As uniquely and compactly designed it is, this mobile concrete mixing plant assembles whole functions of accurate material weighing, efficient aggregate conveying, homogeneous mixing, computer auto-controlling and trailing. It is the ideal concrete plant for projects that require frequent removal from one site to another.
What are the main features of FOCUS mobile concrete mixing plant?
1. Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this mobile concrete mixing plant.
2. Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, twin-shaft mixer offers this mobile concrete mixing plant a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3. Highly precise dosing of water, cement, fly-ash, additive
Focus mobile concrete mixing plant dosing is realized by three-point suspension sensors, and they are all metered separately.
4. Optimized and modular design
FOCUS mobile concrete mixing plant is convenient either for container transport or for towing vehicles.
Parameter:
Install Video of Mobile Portable Concrete Mixing Plant / Batching Plant:
micfocus.en.made-in-china.com
Why would our clients choose FOCUS mobile Concrete Mixing Plant / Batching Plant?
FOCUS MACHINERY boasts an award-wining mobile concrete mixing plant product range with capacity from 25cbm to 120cbm hourly.
This series of mobile concrete mixing plant adopts semi-pulling structure with running system and equipped with standard coupling pin, hence can be dragged by a tractor at the maximum speed of 40km/h.
As uniquely and compactly designed it is, this mobile concrete mixing plant assembles whole functions of accurate material weighing, efficient aggregate conveying, homogeneous mixing, computer auto-controlling and trailing. It is the ideal concrete plant for projects that require frequent removal from one site to another.
What are the main features of FOCUS mobile concrete mixing plant?
1. Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this mobile concrete mixing plant.
2. Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, twin-shaft mixer offers this mobile concrete mixing plant a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3. Highly precise dosing of water, cement, fly-ash, additive
Focus mobile concrete mixing plant dosing is realized by three-point suspension sensors, and they are all metered separately.
4. Optimized and modular design
FOCUS mobile concrete mixing plant is convenient either for container transport or for towing vehicles.
Parameter:
| Model | YHZS25 | YHZS35 | YHZS50/60 | YHZS75 | YHZS120 | |
| Output capacity | 25m³/h | 35m³/h | 50m³-60m³/h | 75m³/h | 100-120m³/h | |
| Overall power | 40kw | 60kw | 85kw | 105kw | 140kw | |
| Discharge height | 3800mm | |||||
| Max. hauling speed | 40km/h | |||||
| warranty | 12months after shipment date | |||||
| After-sale service | Guidance on erecting, commissioning and operator training, 24/7 technical assistance afterwards | |||||
| Concrete mixer | JS500 | JS750 | JS1000 | JS1500 | JS2000 | |
| Motor power | 18.5kw | 30kw | 18.5x2kw | 30x2kw | 37x2kw | |
| Max. aggregate dia. | 80mm | |||||
| Aggregate batcher | PLD800 | PLD1200 | PLD1600 | PLD2400 | PLD3200 | |
| Aggregate weighing precision | ±2% | |||||
| Aggregate feeder | Belt conveyor | |||||
| Other scale scope | Cement | ±1% | ||||
| water | ±1% | |||||
| additive | ±1% | |||||
| Control system | Auto computer control, 1 set | |||||
| Pneumatic system | 1 set | |||||
